GridPulse V360
GridPulse V360 – The Next Generation in Smart Energy Monitoring and Management
In today’s rapidly evolving energy landscape, efficiency, reliability, and control are more important than ever. Industries, utilities, and commercial facilities require solutions that not only monitor energy usage but also optimize performance and support long-term sustainability. To meet these advanced needs, Pulsar Industries proudly introduces GridPulse V360, a cutting-edge energy monitoring and management system engineered to transform the way power networks operate.
GridPulse V360 is built for organizations that rely on accurate data, real-time insights, and seamless system integration. Whether you manage a large industrial facility, operate a commercial plant, or maintain energy infrastructure, this platform provides the intelligence, automation, and visibility required to stay ahead in a competitive world.
A Complete Energy Intelligence Platform
GridPulse V360 is more than just a monitoring tool—it is a comprehensive energy intelligence platform designed to help businesses understand, control, and optimize their energy ecosystem. The solution captures real-time data from multiple energy sources and converts it into actionable insights that enhance performance and reduce operational costs.
With its intuitive dashboard, GridPulse V360 gives users a 360-degree view of their energy network. It identifies inefficiencies, predicts system failures, and simplifies energy planning, making it a valuable asset for both engineers and decision-makers.
Technical Specification
- Mobile Emergency Backup Power for household use mounted on a dolly.
- Wifi-Monitoring app
- Maximum input power: 4000W
- MPPT voltage operating range: 120–450V
- Maximum input voltage: 500VDC.
- Maximum input current: 100A
- Rated energy: 5120Wh.
- Maximum charging voltage: 28.5V.
- Maximum discharge current: 200A.
- Communication: CAN/RS485 comm with inverter.
- MPPT voltage operating range: 120–450V
- Maximum input voltage: 500VDC.
- Maximum input current: 100A
- Rated energy: 5120Wh.
- Maximum AC Voltage Range: 170 – 280VAC. voltage: 28.5V.
- Rated output voltage: 120V
- Weight: 250 lbs.
Expand Your Energy Future
Customize the Gridgo to meet your long-term energy goals with these powerful options:
-
Integrated Solar Ready: Choose the separate dolly option equipped with 4–8 prewired 400W solar panels to turn your unit into an off-grid charging solution.
-
Massive Capacity Expansion: Easily mount Additional Units to the system, allowing you to increase the total capacity up to for extended backup runtime.
| TECHNICAL SPECIFICATION – ECOCHARGE 11 (EC-DC-82X180BHD) | |
|---|---|
| AC INPUT | |
| Voltage Rating | 3×480Vac (±10%, -15%) |
| Max. Input Current | 216A |
| Electrical Distribution | 3P+N+PE (Wye Configuration) |
| Power Grid System | TN/TT and IT |
| Frequency | 50/60Hz |
| Max. Input Power | 184kVA |
| Power Factor | ≥0.99 |
| Efficiency | >94% at Optimum V/I Point |
| AC OUTPUT | |
| Output Voltage Range | CCS1: 200Vdc – 1000Vdc |
| Max. Output Current | 200A |
| Max. Output Power | DC 180kW |
| Simultaneously Output Mode | 0%, 50%, 100%* *Connected EVs will get 50%/50% when two plugs are used simultaneously. |
| Voltage Accuracy | ±1% |
| Current Accuracy | ±1% |
| COMMUNICATION | |
| External | Ethernet, Wi-Fi and 3G/4G |
| Internal | CAN Bus / RS485 |
| Load Management | Via OCPP 1.6 JSON |
| Input Protection | OVP, OCP, OPP, UVP, SPD, RCD |
| Output Protection | OCP, OVP, LVP |
| Internal Protection | OTP, DC Contactor Detection, Fuse Detection |
| Electrical Isolation | Isolation Between Input & Output |
| Standby Power | <100W |
| USER INTERFACE & CONTROL | |
| Display | 7-inch Touchscreen LCD (1024×600) |
| Button | Emergency Shut Off |
| User Authentication | App, WebApp, ISO 15118, Credit Card (Optional), RFID (Optional) |
| Backend Support | OCPP 1.6 JSON (Upgradable to 2.1) |
| ADVERTISEMENT | |
| Display | 55-inch LCD Screen |
| Resolution | TFT-LCD Panel (1920×680) |
| Electrical Distribution | 3P+N+PE (Wye Configuration) |
| ENVIRONMENTAL CONDITIONS | |
| Operation Temperature | -22°F to 131°F (-30°C to 55°C) |
| Storage Temperature | -22°F to 158°F (-30°C to 70°C) |
| Relative Humidity | 5%–95% RH, Non-Condensing |
| Altitude | ≤6560 ft (2000m) |
| REGULATIONS | |
| Safety | UL9540, UL2231 |
| EMI/EMC | UL2231 |
| Charging Interface | CCS DIN 70121 (CCS1) |
| Certification | ETL, ENERGY STAR |
| MECHANICAL SPECIFICATION | |
| Dimensions (W×D×H) | 45.2 × 36.6 × 92.1 inches (1148 × 930 × 2340mm) |
| Weight | 1783.7lbs (800kg), includes two charging connectors |
| DC Charging Connector | 15ft CCS1 Dual Charging Cable |
| Cooling | Fan Cooling |
| Ingress Protection | IP54 NEMA 3R |
| Anti-Vandalism | IK10 (Excludes LCD & RFID) |
